Exquisite processing technology for automotive products, achieving precise hole machining with minimal aperture error control; The conical structure is crafted using advanced processing technology, with a consistent height of taper; Clear and wear-resistant surface engraving, precise details; Special structural design enhances performance, showcasing the precision and high quality of processing technology

Demonstrate consistency and standardized processes in batch processing, precise hole positioning, and surface polishing techniques.

Precision drilling process:

Aperture error ≤ 0.02mm, uniform distribution of hole positions;

Mirror polishing treatment:

Surface roughness Ra ≤ 0.8, m has high metallic luster

Show the second part picture and introduce its conical structure and integrated molding process.

Cone integrated molding: using five axis linkage processing, cone tolerance+0.11 '°, surface without welding steps excessively smooth:

The diameter error of each section is Y0.05mm, and the concentricity is high. The trajectory of each section is smooth

Show the third part picture and introduce its engraving accuracy and positioning hole processing technology.

Laser engraving process: Character depth of 0.1-0.2mm, high clarity, no burrs; Positioning hole processing:

Positioning hole processing: The center distance error between the two holes is ≤ 0.03mm, and the consistency of the hole diameter is good

Show the fourth part picture and introduce its radial heat dissipation structure and CNC milling process.

Radial cutting process:

The thickness of the teeth is uniform, and the spacing error is ≤

0.1mm， Adopting high-speed CNC milling for forming;

Precision machining of inner holes:

Inner hole surface smoothness Ra ≤ 1.6, m,

The clearance with the shaft is 0.05-0.1mm
